VMS-V-9K-48-H/HG — 9000W Hybrid Solar Inverter
Get Quotation
| MODEL | VMS-V-9K-48-H/HG |
| Rated Power | 9000W |
| Voltage | 220/230/240VAC |
| Output Waveform | Pure sine wave |
| Frequency Range | 50 Hz/60 Hz |
| Selectable Voltage Range | 170-280VAC (PC) 90-280VAC (Appliances) |
| Feed-in Grid Voltage Range | 195-253VAC |
| Feed-in Grid Frequency Range | 49-51±1HZ/59-61±1HZ |
| Maximum Load | 9000W |
| Dimension DxWxH (mm) | 147×432×553 |
| Net Weight (kg) | 17.2 |
| Humidity | 5%~95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to -50°C |
| Storage Temperature | -15°C to -60°C |
Description
The VMS-V-9K-48-H/HG is a 9,000W on/off grid hybrid solar inverter built for large residential systems, small commercial facilities, and multi-unit buildings with substantial and diverse energy loads. Pure sine wave output at 220/230/240VAC handles the full range of appliances, HVAC systems, industrial-grade tools, and sensitive electronics running simultaneously.
Supports 50Hz and 60Hz, selectable voltage 170–280VAC (PC) / 90–280VAC (appliances), feed-in grid 195–253VAC, frequency tolerance 49–51±1Hz / 59–61±1Hz. Maximum load 9,000W. Weighs 17.2kg in the 147×432×553mm enclosure. Operating temperature -10°C to +50°C, storage -15°C to +60°C, humidity 5%–95% non-condensing.
Technical specifications
| Model | VMS-V-9K-48-H/HG |
| Rated power | 9,000W |
| Maximum load | 9,000W |
| Voltage | 220 / 230 / 240VAC |
| Output waveform | Pure sine wave |
| Frequency range | 50Hz / 60Hz |
| Selectable voltage range | 170–280VAC (PC) / 90–280VAC (Appliances) |
| Feed-in grid voltage | 195–253VAC |
| Feed-in grid frequency | 49–51±1Hz / 59–61±1Hz |
| Dimension DxWxH (mm) | 147×432×553 |
| Net weight | 17.2kg |
| Humidity | 5%–95% RH (Non-condensing) |
| Operating temperature | -10°C to +50°C |
| Storage temperature | -15°C to +60°C |
Key features
- 9,000W continuous load — large homes & small commercial
Sustains 9KW of simultaneous load — covering heavy HVAC, commercial kitchen equipment, workshop machinery, and full office fit-outs running concurrently without load-shedding.
- 48V battery system — higher efficiency at scale
The 48V battery bus architecture delivers better conversion efficiency and lower current draw versus 24V systems at equivalent power, reducing heat generation and cable sizing requirements.
- Pure sine wave — 220/230/240VAC
Full grid-quality output safe for variable-speed motor loads, inverter-driven air conditioners, server equipment, and medical devices — not just basic resistive appliances.
- Selectable voltage range — PC and appliance modes
Configurable output tolerance per load type: 170–280VAC for computers, 90–280VAC for home appliances — protects sensitive equipment on a single shared installation.
- Wide grid tolerance — 195–253VAC / 49–51±1Hz
Broad grid acceptance band minimises nuisance disconnections on unstable supply networks common in commercial and developing-market installations.
- Compact despite 9KW output — 147×432×553mm
Same enclosure as the 4.2KW and 6.2KW models — fits the same wall-mount bracket with no installation changes. At 17.2kg it reflects the denser 48V transformer, but remains single-engineer installable.
